For PCB fabrication, we require PCB design file in Gerber RS-274X format (most preferred), *.PCB/DDB (Protel, inform your program version) format or *.BRD (Eagle) format.
Generally, there is no minimum order quantity (MOQ) requirement for the pcb order.
We guarantee a response to all quotation requests within 24 hours.
We utilize the latest and most efficient manufacturing technologies, ensuring both time and cost savings for your projects.
With over 20 years of combined expertise, we specialize in delivering advanced PCB assembly and manufacturing services.
Trace width: 3 mils
Trace/line spacing: 3 mils
When working with narrower traces, the tolerance becomes tighter, which can lead to over-etching. However, our controlled etching process ensures accurate trace widths are achieved.
We can use nearly all solder mask colors. The most frequently used options include Red, Green, Black, Blue, and White.
We offer a variety of surface finishes, including HASL, Lead-free HASL, ENIG, Immersion Silver, Immersion Tin, OSP, Soft Wire Bondable Gold, and Hard Gold.
Mechanical drilling: 6 mils
Laser drilling: 4 mils
Including various hole sizes in a PCB design necessitates the use of additional drill bits during manufacturing, which can lead to higher costs and longer production times.
Yes, we offer free impedance control calculations and stack-up design using industry-leading field solvers. Impedance control involves aligning PCB trace dimensions and placements with the substrate material’s properties to ensure signal strength remains within the desired range. By adhering to best design practices, many potential signal integrity issues can be prevented or minimized.
Yes, we can produce panels containing multiple board types. However, we will need to review your design files before providing a final confirmation.
Yes, we do.
A peelable solder mask is used to protect specific areas of a PCB during the assembly process, particularly during wave soldering. It ensures that solder does not come into contact with the designated protected regions.
Yes, we specialize in manufacturing both flexible and rigid-flex PCBs.
We utilize two primary testing methods:
1. Flying Probe
2. Test Fixture
Yes, we are equipped to produce PCBs designed for high-frequency and RF applications.
Yes, we offer metal core PCBs with support for up to 6 layers
Yes, we have the capability to bevel hard gold fingers.
No, we offer PCB panelization free of charge.
Yes, we are capable of producing HDI PCBs. For further details, please visit our PCB Fabrication page. HDI PCBs achieve greater circuit density compared to traditional PCBs by incorporating advanced features and technologies, including blind/buried vias, laser-drilled stacked micro-vias, via-in-pad techniques, and more.
Yes, we offer castellation hole services.
We recommend using the largest hole size feasible for optimal results.
Yes, we provide V-scoring for bare PCB orders as needed.
1. Board quantity
2. PCB thickness
3. Number of layers
4. Copper weight
5. HDI features
6. Routing complexity
7. Impedance control requirements
Yes, we offer both controlled-depth routing and special milling.
We utilize a wide range of laminates, including FR4, High TG FR4, Rogers, Arlon, Aluminum Base, Polyimide, Ceramic, Taconic, Megtron, and more.
Yes. But we also offer leaded PCBs.
