Product Overview
Our high-performance thermal pad PCB provides superior thermal conductivity and electrical insulation between heat-generating components and heat sinks or chassis. Engineered for optimal heat dissipation in demanding electronic applications, this thermal interface material ensures reliable component operation and extended product lifespan.
Key Features
Superior Thermal Performance
- High thermal conductivity rating of 1.5-8.0 W/mK depending on thickness
- Low thermal resistance for efficient heat transfer
- Excellent thermal stability across wide temperature ranges (-40°C to +200°C)
Reliable Electrical Insulation
- High dielectric strength (>4kV/mm) prevents electrical shorts
- Low electrical conductivity ensures component isolation
- Maintains insulation properties over extended operating periods
Easy Installation & Application
- Pre-cut sizes available for standard component packages
- Conformable material adapts to surface irregularities
- No curing time required – immediate thermal performance
- Clean, residue-free removal when replacement is needed
Durable Construction
- Silicone-based material with reinforced structure
- Resistant to compression set and mechanical stress
- Chemical resistance to oils, solvents, and cleaning agents
- Long-term reliability in harsh operating environments
Technical Specifications
- Material: High-grade silicone with ceramic fillers
- Thickness Range: 0.5mm to 5.0mm (custom thicknesses available)
- Hardness: Shore 00 25-45 (depending on grade)
- Operating Temperature: -40°C to +200°C continuous
- Thermal Impedance: 0.8-3.5°C·in²/W
- Flame Rating: UL94 V-0
- Color: Gray, Pink, or Blue (varies by thermal grade)
Applications
Power Electronics
- CPU and GPU thermal management
- Power MOSFETs and IGBTs
- LED lighting assemblies
- Power supply modules
Industrial Equipment
- Motor drives and inverters
- Welding equipment
- Industrial controllers
- Battery management systems
Automotive Electronics
- ECU thermal management
- Electric vehicle power systems
- LED headlight assemblies
- Charging infrastructure
Telecommunications
- Base station amplifiers
- Network switching equipment
- Data center servers
- Optical transceivers
Available Configurations
- Standard Sheets: 100mm x 100mm, 200mm x 300mm
- Die-Cut Parts: Custom shapes for specific components
- Adhesive Backing: Single or double-sided options available
- Thickness Options: 0.5mm, 1.0mm, 1.5mm, 2.0mm, 3.0mm, 5.0mm
Quality & Compliance
- RoHS compliant and halogen-free
- UL recognized components
- ISO 9001:2015 certified manufacturing
- REACH regulation compliant
- Extensive quality testing including thermal cycling and aging tests
Why Choose Our Thermal Pads?
Our thermal pad PCB solutions deliver consistent, reliable thermal management performance that engineers trust for critical applications. With rigorous quality control, extensive testing, and proven field reliability, these thermal interface materials provide the perfect balance of thermal conductivity, electrical isolation, and mechanical durability.
Contact us today for technical specifications, custom sizing options, or application engineering support to optimize your thermal management solution.
