Overview
Our PCB fans deliver reliable active cooling for compact electronic applications where thermal management is critical. These miniature cooling solutions are specifically engineered for direct mounting on printed circuit boards, providing targeted airflow to prevent component overheating and ensure optimal system performance.
Key Features
Compact Design: Ultra-low profile construction fits seamlessly into space-constrained PCB layouts without compromising board real estate or adjacent components.
Direct PCB Integration: Through-hole and surface-mount options available for secure mechanical and electrical connection directly to your circuit board design.
Efficient Airflow: Optimized blade geometry and motor design deliver maximum air movement per watt, ensuring effective heat dissipation from critical components like processors, power modules, and high-density circuits.
Low Noise Operation: Advanced bearing systems and balanced rotors minimize acoustic emissions, making them ideal for noise-sensitive applications including medical devices, audio equipment, and office electronics.
Wide Operating Range: Designed to function reliably across extended temperature ranges (-20ยฐC to +70ยฐC) with consistent performance under varying environmental conditions.
Technical Specifications
- Voltage Range: 3.3V, 5V, 12V, and 24V options available
- Current Draw: As low as 50mA for energy-efficient operation
- Airflow: 0.5 to 15 CFM depending on size and voltage
- Dimensions: Available in 25mm, 30mm, 40mm, and 60mm square formats
- Speed Control: PWM and analog control options for variable speed operation
- Bearing Types: Ball bearing and sleeve bearing configurations
- Lifespan: Up to 50,000 hours MTBF at 25ยฐC
Applications
Perfect for cooling processors, FPGAs, power supplies, LED drivers, industrial controllers, telecommunications equipment, and any PCB-mounted application requiring localized thermal management. Particularly valuable in embedded systems, IoT devices, and compact electronic assemblies where traditional heatsink solutions are impractical.
Quality & Reliability
Each fan undergoes rigorous testing for vibration resistance, thermal cycling, and long-term reliability. RoHS compliant with UL recognition available for safety-critical applications.
Transform your thermal management strategy with precision-engineered PCB fans that deliver powerful cooling performance in the smallest possible footprint.
