High-Performance Mid Loss PCB Solutions for Professional Electronics
Our mid loss PCB (Printed Circuit Board) technology delivers the perfect balance between signal integrity and cost-effectiveness for demanding RF, microwave, and high-frequency applications. Engineered with advanced dielectric materials, these circuit boards offer superior performance characteristics that make them ideal for telecommunications, aerospace, automotive, and industrial electronics.
Key Features of Our Mid Loss PCB Technology
Superior Signal Performance
- Low dielectric loss tangent (typically 0.002-0.010)
- Excellent signal-to-noise ratio maintenance
- Reduced insertion loss across wide frequency ranges
- Stable electrical properties from DC to millimeter wave frequencies
Advanced Material Construction
- High-quality FR4 and specialized dielectric substrates
- Controlled impedance matching (ยฑ5% tolerance)
- Temperature-stable performance (-55ยฐC to +125ยฐC)
- Low moisture absorption for enhanced reliability
Precision Manufacturing
- Tight layer-to-layer registration
- Consistent copper thickness control
- Advanced via technology for minimal signal degradation
- Industry-leading quality control standards
Applications for Mid Loss PCB
RF and Microwave Systems
- Wireless communication equipment
- Radar and satellite systems
- Base station infrastructure
- Antenna feed networks
High-Speed Digital Applications
- Data center equipment
- High-speed computing systems
- Test and measurement instruments
- Signal processing boards
Automotive Electronics
- Advanced driver assistance systems (ADAS)
- Vehicle-to-everything (V2X) communication
- Infotainment systems
- Electronic control units (ECUs)
Technical Specifications
- Dielectric Constant (Dk): 3.0-4.5 (frequency dependent)
- Loss Tangent: 0.002-0.010 @ 10GHz
- Thermal Coefficient: ยฑ50ppm/ยฐC
- Layer Count: 2-32 layers available
- Board Thickness: 0.2mm-6.0mm
- Copper Weight: 0.5oz-4oz
- Surface Finish: HASL, ENIG, OSP, ImAg options
Why Choose Our Mid Loss PCB Solutions?
Cost-Effective Performance Our mid loss PCBs provide exceptional RF performance at a fraction of the cost of ultra-low loss alternatives, making them perfect for applications where budget constraints exist without compromising signal quality.
Proven Reliability Manufactured to IPC-A-600 and IPC-6012 standards, our boards undergo rigorous testing including thermal cycling, moisture resistance, and electrical performance validation.
Fast Turnaround Standard lead times of 5-10 business days with expedited options available for urgent projects.
Technical Support Our experienced engineering team provides comprehensive design support, impedance matching calculations, and application guidance.
Industries We Serve
- Telecommunications: 5G infrastructure, wireless base stations, network equipment
- Aerospace & Defense: Radar systems, satellite communications, military electronics
- Automotive: Connected vehicle systems, autonomous driving technology
- Industrial: IoT devices, sensor networks, automation equipment
- Medical: Imaging systems, diagnostic equipment, patient monitoring
Quality Certifications
- ISO 9001:2015 Quality Management
- IPC-A-600 Acceptability Standards
- IPC-6012 Qualification and Performance
- UL Recognition for safety compliance
- RoHS compliant materials
Custom Mid Loss PCB Design Services
Our engineering team offers comprehensive design services including:
- Stack-up optimization for your specific requirements
- Impedance matching and signal integrity analysis
- Thermal management solutions
- DFM (Design for Manufacturing) consultation
- Prototype development and testing
Get Your Mid Loss PCB Quote Today
Ready to experience the perfect balance of performance and value? Contact our technical sales team for a customized quote on your mid loss PCB requirements. We offer competitive pricing, fast turnaround times, and unmatched technical support.
