Advanced Medical Electronics for In-Vivo Applications
Our implantable PCBs represent the cutting edge of biomedical engineering, designed specifically for long-term integration within the human body. These specialized circuit boards combine sophisticated electronic functionality with proven biocompatibility standards, enabling the next generation of medical devices and therapeutic solutions.
Key Features
Biocompatible Materials & Coatings Constructed using FDA-approved substrates and protective coatings that resist biological degradation while preventing adverse tissue reactions. Surface treatments ensure seamless integration with surrounding tissues and minimize inflammatory responses.
Ultra-Miniaturized Design Engineered for maximum functionality in minimal footprint configurations. Advanced manufacturing techniques enable complex circuitry in packages as small as 2mm x 2mm, ideal for minimally invasive procedures and sensitive anatomical locations.
Hermetic Sealing Technology Multi-layer encapsulation provides complete protection against bodily fluids while maintaining electrical performance. Our proprietary sealing process ensures reliable operation for 10+ years in the challenging biological environment.
Flexible & Rigid Options Available in both rigid ceramic substrates for durability and flexible polymer configurations that conform to tissue movement. Hybrid designs combine the benefits of both approaches for specific anatomical requirements.
Applications
- Neural Interfaces: Deep brain stimulation, cochlear implants, retinal prosthetics
- Cardiac Devices: Pacemakers, defibrillators, cardiac monitoring systems
- Drug Delivery Systems: Programmable medication dispensers, insulin pumps
- Biosensors: Continuous glucose monitors, intracranial pressure sensors
- Therapeutic Stimulation: Spinal cord stimulators, peripheral nerve interfaces
Technical Specifications
- Operating Temperature: 32°C to 42°C (body temperature range)
- Moisture Resistance: IP68 rated for permanent immersion
- Biocompatibility: ISO 10993 certified, USP Class VI compliant
- Sterilization: Compatible with gamma, e-beam, and EtO sterilization
- Trace Width: Down to 25 micrometers for high-density routing
- Layer Count: 2-16 layers depending on complexity requirements
Quality & Compliance
Each implantable PCB undergoes rigorous testing including accelerated aging studies, biocompatibility assessments, and electrical performance validation. Our manufacturing facility maintains ISO 13485 certification and operates under FDA Quality System Regulation (QSR) guidelines.
Perfect for medical device manufacturers developing next-generation implantable technologies that demand the highest standards of reliability, safety, and performance.
Custom designs available with full engineering support from concept through regulatory approval.
