Ensure reliable power delivery across your electronic systems with our comprehensive Power Distribution Testing services. Our advanced testing solutions validate the performance and stability of power distribution networks (PDNs) in PCBs, ICs, and complex electronic assemblies.
Key Features:
- Comprehensive PDN Analysis: Evaluate power rail performance, voltage regulation, and current distribution across all power domains
- Real-time Monitoring: Continuous assessment of power quality, ripple, noise, and transient response under various load conditions
- Multi-domain Testing: Support for digital, analog, and mixed-signal circuits with specialized test protocols for each domain
- Advanced Measurement Capabilities: High-precision voltage and current measurements with sub-millivolt and sub-milliamp resolution
- Automated Test Sequences: Streamlined testing workflows that reduce manual intervention and improve repeatability
Applications:
- Pre-silicon validation of power management designs
- Post-layout verification of PCB power distribution networks
- Production testing of power delivery systems
- Failure analysis and root cause identification
- Compliance testing for industry standards (USB-C PD, PoE, automotive)
Technical Capabilities:
- Voltage range: 0.1V to 100V with 0.1mV accuracy
- Current measurement: 1µA to 100A with high dynamic range
- Frequency analysis: DC to 10GHz for power integrity characterization
- Multi-channel synchronized measurements up to 256 channels
- Temperature coefficient testing from -40°C to +150°C
Benefits:
- Reduce time-to-market with early detection of power delivery issues
- Minimize field failures through comprehensive pre-production validation
- Optimize power efficiency and thermal performance
- Ensure regulatory compliance and safety standards
- Lower overall system costs through improved design reliability
Ideal for semiconductor manufacturers, PCB designers, automotive electronics, telecommunications equipment, and consumer electronics companies requiring robust power distribution validation.
