Transform your electronic projects with our versatile LED Matrix PCB, engineered for seamless array configurations and brilliant visual displays. This high-quality printed circuit board provides the foundation for creating stunning LED matrices in various sizes and arrangements.
Key Features
Flexible Array Options – Supports multiple LED configurations from compact 8×8 grids to expansive custom arrays, accommodating projects of any scale.
Premium PCB Construction – Built with durable FR4 substrate and precision-etched copper traces for reliable performance and long-lasting operation.
Easy Integration – Standard pin spacing and clearly marked connection points ensure straightforward integration with microcontrollers, Arduino boards, and other control systems.
Optimized Current Distribution – Intelligent trace routing minimizes voltage drop and ensures uniform brightness across all LED positions.
Modular Design – Stackable and chainable architecture allows for creating larger displays by connecting multiple boards seamlessly.
Technical Specifications
- Compatible LED Types: 3mm, 5mm through-hole and surface-mount LEDs
- Maximum Current Rating: 20mA per LED position
- Operating Voltage: 3.3V to 5V DC
- PCB Thickness: 1.6mm standard
- Finish: HASL (Hot Air Solder Leveling) or ENIG available
- Temperature Range: -40°C to +85°C
Applications
Perfect for digital signage, scrolling text displays, gaming projects, artistic installations, educational demonstrations, and prototype development. Whether you’re building a simple status indicator or a complex animated display, this LED matrix PCB provides the reliable foundation you need.
*Package includes PCB only – LEDs and control components sold separately
