4-Layer Rigid-Flex PCB Pricing Guide

When it comes to pricing for a 4-layer Rigid-Flex PCB, it’s important to note that costs can vary significantly based on several factors.

Factors Affecting Price

  1. Board Size: Larger boards generally cost more.
  2. Quantity: Higher quantities typically reduce per-unit cost.
  3. Material Quality: High-performance materials increase cost.
  4. Copper Weight: Heavier copper is more expensive.
  5. Surface Finish: ENIG is typically more expensive than HASL.
  6. Minimum Trace/Space: Tighter tolerances increase cost.
  7. Via Technology: Micro vias or buried vias add to the cost.
  8. Turnaround Time: Faster production usually costs more.

Estimated Price Ranges

Note: These are rough estimates and can vary widely based on the factors mentioned above and the specific manufacturer.

  • Low Quantity (1-10 pieces):

    • Small size (e.g., 2″ x 3″): $100 – $300 per board
    • Medium size (e.g., 4″ x 6″): $200 – $500 per board
    • Large size (e.g., 8″ x 10″): $400 – $1000+ per board

  • Medium Quantity (50-100 pieces):

    • Small size: $50 – $150 per board
    • Medium size: $100 – $300 per board
    • Large size: $200 – $600 per board

  • High Quantity (1000+ pieces):

    • Small size: $20 – $80 per board
    • Medium size: $50 – $150 per board
    • Large size: $100 – $300 per board

Additional Costs to Consider

  1. Tooling charges: One-time fee, typically $100 – $500
  2. Testing fees: May be charged separately, especially for complex boards
  3. Shipping costs: Can be significant for international orders
  4. Expedited manufacturing: Can increase costs by 30-100%

Tips for Cost Reduction

  1. Optimize design for manufacturing
  2. Consider standard material options when possible
  3. Increase order quantity if feasible
  4. Plan ahead to avoid rush fees
  5. Consolidate orders with the same manufacturer

Getting Accurate Quotes

For precise pricing:

  1. Prepare detailed design files (Gerber files, BOM, etc.)
  2. Specify all requirements clearly
  3. Request quotes from multiple manufacturers
  4. Consider both domestic and overseas options
  5. Discuss DFM (Design for Manufacturing) with potential manufacturers

Remember, the complexity of rigid-flex PCBs often results in higher prices compared to standard rigid PCBs. Always balance cost with quality and reliability requirements for your specific application.
