The Panasonic Corporation is a well-known company that keeps adding value to the electronics industry. The company produced the halogen-free MEGTROL R-5375 laminate. With the recent development in the electronics industry, there is a need for ultra-low loss PCB material. Also, there is a need for faster data transmission speeds in the communication industry.
Multilayer PCB materials are a core component in equipment like routers and servers. Therefore, this equipment needs halogen-free PCB material for environmental protection. Also, the need for high-speed data transmission is crucial in this application. However, Panasonic offers PCB material that meets all of these needs.
What is Panasonic Halogen-free MEGTRON6 R-5375 Laminate?
The MEGTRON6 R-5375 Laminate is an halogen-free PCB material designed by Panasonic. This multilayer PCB material is ideal for communication infrastructure equipment. Also, it is a halogen-free PCB material that offers high reliability and low transmission loss. Therefore, this contributes to faster data transmission.
This PCB material enhances the fabrication of multilayer PCBs with more than 20 layers. Also, this halogen-free PCB material has a low dielectric constant and dissipation factor. MEGTRON6 R-5375 Laminate offers great electrical and thermal features.
Features of Panasonic Halogen-free MEGTRON6 R-5375 Laminate
Panasonic Halogen-free MEGTRON6 R-5375 is a halogen-free laminate. Therefore, this material is safe for the environment. There is a growing demand for environment-friendly material for PCBs used in communication infrastructure equipment. The use of this material helps to maintain flame retardation in PCBs.
Low transmission loss
Low transmission loss is crucial in the telecommunication industry. Materials featuring low transmission loss offer high data transmission. The use of resin design technology in this material helps to achieve low transmission loss. Also, Panasonic Halogen-free MEGTRON R-5375 Laminate contributes to the development of the 5G mobile communication system.
Panasonic Halogen-free MEGTRON R-5375 Laminate features high heat-resistance. Due to this feature, this material enhances reliable operation. Also, the use of compound technology and resin design technology helps to achieve this feature. This multilayer PCB material features excellent reliability in extreme temperature environments.
Ease of multilayer PCB manufacturing
Panasonic Halogen-free MEGTRON R-5375 Laminate improves the processing of multilayer PCBs with more than 20 layers. Also, this laminate achieves excellent ease of manufacturing of multilayer boards.
Basic Specifications of Panasonic Halogen-free MEGTRON6 R-5375 Laminate
- The R-5375 (N) laminate is a low dielectric constant glass cloth
- R-5375(E) is a E-glass cloth halogen-free laminate
- R-5370(N) is a prepreg
- R-5370(E) is also a prepreg
Properties of Panasonic Halogen-free MEGTRON R-5375 Laminate
Panasonic Halogen-free MEGTRON R-5375 laminate features excellent thermal and electrical properties. These properties contribute to the exceptional performance of this PCB material.
Low and stable Dk
The dielectric constant of this PCB material is very low. Also, it is stable across a wide frequency range. The Dk indicates the ease of polarization of an insulator when there is an external charge. The Dk value of this material is 3.4 at 12 GHz. Also, easily-polarized materials (high Dk) can store electricity. However, hardly-polarized materials (small Dk) are ideal for transmitting electrical signals.
Low and stable Df
The dissipation factor of this material is very low and stable. Panasonic Halogen-free MEGTRON R-5375 Laminate has a Df value of 0.004. Also, this electrical property measures the degree of loss that occurs when electricity in an insulation substance discharges. Materials with low Df are more efficient at discharging stored electricity. Therefore, Panasonic Halogen-free MEGTRON R-5375 Laminate reduces electrical signal loss.
The glass transition temperature of this material is very high. Panasonic Halogen-free MEGTRON R-5375 Laminate features a Tg of 250 degrees Celsius. Also, this property measures how a material changes to a rubber-like state after it is heated. With a high Tg value, this material can withstand extreme temperatures.
Low Z-axis expansion
The z-axis expansion of this material is 1.7% at 50-260 degrees Celsius. This is a very low value. Therefore, this material can hardly expand in size when exposed to high degrees of temperature.
Excellent peel strength
The peel strength of this material is 0.6 KN/m at IPC-TM-650 2. 4. 8. Therefore, this material maintains a high peel strength.
Factors to Consider when Choosing Panasonic Halogen-free MEGTRON R-5375 Laminate
Panasonic Corporation designed various PCB materials. The Panasonic Halogen-free MEGTRON R-5375 Laminate meets specific requirements. Therefore, it is very important to choose a material that suits your application requirements.
This is a factor you need to consider before choosing Panasonic Halogen-free MEGTRON R-5375 laminate. Also, heat resistance is a crucial factor in high frequency applications.
Signal integrity is critical in the telecommunication industry. Most communication infrastructure devices require signal integrity for great performance. Panasonic Halogen-free MEGTRON R-5375 Laminate enhances signal integrity in applications. If signal integrity is a major concern, then this PCB material is an ideal choice.
PCBs used for communication networks need to be free from any halogen constituents. Also, this is very crucial for environmental protection. Therefore, when choosing a PCB material, consider the safety of the environment. Panasonic Halogen-free MEGTRON R-5375 Laminate is completely free of halogen.
Panasonic Halogen-free MEGTRON R-5375 Laminate features distinct electrical and thermal properties. These properties are responsible for the high performance of this material. Therefore, ensure these properties meet the requirements of your PCB project. For instance, if you need a material with low Dk and low Df value, this material is suitable.
Applications of Panasonic Halogen-free MEGTRON R-5375 Laminate
Panasonic Halogen-free MEGTRON R-5375 Laminate is widely used in the communication system. It is particularly used in mobile communication systems. You will find this PCB material in routers and servers. This material is highly efficient in applications that demand low transmission loss.
Also, you will find this material in communications infrastructure equipment and wireless base stations. This material offers signal integrity and reduces signal loss. Therefore, it plays a crucial role in high-end switches and servers. This material has positively impacted the communication industry. This material is suitable for applications like:
- Wireless base stations
- ICT infrastructure equipment
This article has shed more light on Panasonic Halogen-free MEGTRON R-5375 Laminate. Also, it discussed the application areas and features of this PCB material.
