What is Keyboard PCB Tester?

A keyboard PCB tester is a device used to test the functionality and connectivity of a printed circuit board (PCB) designed for a computer keyboard. Keyboard PCB testers allow manufacturers and hobbyists to validate all aspects of a keyboard PCB design before assembling the final keyboard.

Keyboard PCB testers verify the following functions:

  • Electrical connectivity between switches, microcontrollers, and other PCB components
  • Switch matrix scanning operation
  • MIDI/audio output signal generation
  • Compatibility with keyboard firmware
  • Full N-key rollover (NKRO) capability

Why Use a Keyboard PCB Tester?

There are several key benefits to using a keyboard PCB tester during the design and manufacturing process:

Validate PCB Trace Integrity

The PCB tester can validate that all intended electrical connections have been properly etched into the PCB during fabrication. This ensures no broken or partial traces exist on the board that would prevent correct switch matrix scanning.

Reduce Costly Re-spins

By fully testing a keyboard PCB before production, any design flaws can be identified early. This avoids costly PCB re-spins later in the development cycle.

Verify Firmware Compatibility

Testing the PCB with keyboard firmware loaded confirms the microcontroller chip can properly interface with the PCB hardware. Incompatibilities can be addressed in either the PCB or firmware.

Check N-Key Rollover Capability

Keyboard testers enable validating that no ghosting issues occur, even when many keys are pressed simultaneously. This confirms the keyboard matrix can support full NKRO operation.

Streamline Manufacturing Testing

Performing comprehensive tests with a keyboard PCB tester means less testing is needed later during production. This saves manufacturing time and cost.

What to Look for in a Keyboard PCB Tester

There are several key factors to evaluate when selecting a keyboard PCB tester:

Switch Matrix Test Interface

The tester should provide an interface to mount the keyboard PCB and connect switches installed in each position of the switch matrix. This allows scanning of the complete matrix.

Matrix SizeNumber of Switches
100% / Full100-110

Integrated Keycap Simulators

High-quality testers come with physical key actuators to simulate key presses. These can validate the sensor/switch mechanism and provide a realistic typing feel.

MIDI and Audio Output

Test MIDI and audio output generation from the keyboard PCB by connecting to external speakers or a Digital Audio Workstation (DAW).

Firmware Loading Capability

There should be a method to load the keyboard’s firmware onto the microcontroller to test full functionality and compatibility.

NKRO Testing Features

Advanced testers provide specialized interfaces to press multiple switches simultaneously. This confirms the keyboard matrix and firmware supports full NKRO.

Multimeter Probes

Some testers integrate digital multimeter probes to measure continuity, resistance, capacitance, and voltage of PCB components and traces during testing.

Debugging Interfaces

Interfaces like JTAG or SWD allow advanced debugging of the keyboard microcontroller firmware and low-level operation.

Types of Keyboard PCB Test Solutions

There are a variety of keyboard PCB test solutions available depending on application requirements and budget.

Custom Test Fixtures

Fixtures consist of an array of mechanical switches mounted to a baseplate to interface with the keyboard PCB switches and simulate key presses. Custom fixturing provides flexibility to accommodate different PCB sizes but requires fabrication expertise.

Universal Testers

Universal keyboard testers feature an adjustable housing to adapt to different PCB sizes. They integrate keycap simulators, MIDI/Audio validation tools, and debugging features into a single device. These provide excellent functionality but at a high cost.

Popular universal testers include:

  • GoKey Tester
  • SO Layer Electronic Keyboard Tester

DIY Testing Stations

Hobbyists often create custom testing devices using DIY electronics kits or prototyping boards like Arduino or Raspberry Pi. These low-cost platforms can interface with keyboard matrices to validate basic functionality but require significant development effort.

Performing Tests with a Keyboard PCB Tester

The general workflow for testing a keyboard PCB consists of:

1. Mount the PCB

Secure the keyboard PCB into the tester interface with the switch positions properly aligned.

2. Install Firmware

If testing with firmware, load the keyboard firmware hex file onto the microcontroller.

3. Connect Power

Connect the appropriate power source to turn on the keyboard PCB. USB or battery power are typical.

4. Actuate Switches

Manually press buttons on the integrated keycap simulators or external keyboard to actuate each switch position.

5. Validate Matrix Scanning

Monitor the keyboard protocol data using debug software to validate the firmware detects each switch actuation.

6. Test MIDI/Audio Output

If MIDI/Audio features are supported, validate correct waveform generation by connecting speakers or MIDI recording software.

7. Validate NKRO

Using a specialized NKRO interface, press an array of keys simultaneously to confirm no ghosting or blocking occurs.

8. Debug Issues

Use integrated tools like multimeter probes or debugging interfaces to diagnose and fix issues with traces, solder joints, components, or firmware.

Application Examples of Keyboard PCB Test Fixtures

Keyboard PCB testers enable a wide range of applications during design, pre-production, and manufacturing:

Research & Development

Engineers use keyboard test fixtures during R&D to validate PCB designs iteratively without needing complete prototypes.

Design Verification

Quality engineers can formally verify all acceptance criteria are met for connectivity, scanning, rollover, and output generation using detailed test procedures.

Production Line Testing

Streamlined validation procedures with keyboard PCB testers during manufacturing reduce the overhead of quality control processes.

Safety & Compliance

Testing helps certify each keyboard PCB meets electrostatic standards or is compliant with electrical safety regulations for the target market.

Partner/Supplier Qualification

Brands qualifying PCB or electronic component vendors utilize testing to ensure suppliers meet quality benchmarks.

Fault Diagnosis & Repair

Hobbyists and repair technicians leverage DIY keyboard testers to efficiently troubleshoot issues with non-functional keyboards.


Corne keyboard PCB
Corne keyboard PCB

Keyboard PCB testers enable validation of all functional aspects of a keyboard PCB design before assembling the final keyboard enclosure and keycaps. By thoroughly testing the bare PCB, manufacturers can identify issues early and reduce costly re-spins later in the process. From simple custom test fixtures to advanced universal solutions, there are tester configurations available for any application need and budget. As keyboards become increasingly complex, keyboard PCB test instrumentation will continue growing as an essential tool for design, pre-production verification, manufacturing, and service workflows.

Frequently Asked Questions

What are the key functions tested by a keyboard PCB tester?

The main functions validated by keyboard PCB testers include: electrical connectivity between PCB components, switch matrix scanning operation, MIDI/audio signal generation, firmware compatibility, and N-key rollover capability.

When in the design flow are keyboard PCB testers used?

Keyboard PCB testers are primarily used to validate designs after fabrication of the bare PCB and before enclosure assembly. This enables issues to be identified early before large production runs occur.

What interface is used to actuate the PCB switches during testing?

Most universal keyboard PCB testers utilize physical actuators to press each switch on the board and simulate key presses. Custom test fixtures generally interface bare switches to mechanically activate the PCB switch sites.

Can hobbyists create their own keyboard testing devices?

Yes, hobbyists can construct custom DIY keyboard test devices using kits based on platforms like Arduino or Raspberry Pi. These low-cost tools allow basic validation but require significant development work.

How are multiple simultaneous key presses tested to validate NKRO ?

Advanced commercial keyboard PCB testers come equipped with specialized interfaces to allow pressing large arrays of keys at once. Signals can then be monitored to check no ghosting or blocking occurs during extreme conditions.
