Category: RF & Microwave PCB

RF (Radio Frequency) and microwave PCBs are specialized circuit boards designed to operate at high frequencies, typically from 3 MHz up to 100+ GHz. These PCBs are critical in applications like 5G communications, aerospace, radar systems, and satellite technology. Unlike standard PCBs, they use low-loss dielectric materials (e.g., Rogers RO4000®, PTFE, or ceramic-filled laminates) to minimize signal attenuation and maintain stable impedance. Key considerations include controlled dielectric constant (Dk), low dissipation factor (Df), and precise trace geometries to prevent signal reflections. Advanced fabrication techniques, such as laser drilling and tight tolerance etching, ensure optimal performance in demanding RF environments.
